Check Before Operating
16
IMPORTANT: It is preferable to blow dirt
out (Fig. 10), rather than washing it out. If
water is used, keep it away from electrical
items.
m–3615
Figure 10
IMPORTANT: DO NOT HIGH–PRESSURE
WASH. High–pressure washing can damage
the electrical system or deplete grease.
6. The rear transaxle cover is an air intake area for
cooling the transaxle. Clean debris from the rear
transaxle cover before operating the tractor (Fig.
11).
1
m–3436
Figure 1
1
1. Rear
transaxle cover
Check
the Safety Interlock
System
Always check the interlock system before operating
the tractor. Instructions for checking the interlock
system are found in the Operation section, page 17.
Check
the Brake
Refer to Checking and Adjusting the Brake, page 36.
