Maintenance
43
Taillights
Bulb: GE 194
Removing the Bulb
1. Disengage the power take off (PTO), set the
parking brake, lower the attachment lift, and turn
the ignition key to “STOP” to stop the engine.
Remove the ignition key.
2. Remove the two screws.
3. Pull the lens out far enough so that you can
remove the bulb socket.
4. Pull the bulb from the socket.
1
m–3321
2
3
3
Figure 51
1. Lens
2. Screws
3. Bulb
4. Socket
Installing the Bulb
Reverse the bulb removal procedure.
Battery
Service Interval/Specification
Check the electrolyte level in the battery every 25
hours. Always keep the battery clean and fully
charged. Use a paper towel to clean the battery case.
If the battery terminals are corroded, clean them with
a solution of four parts water and one part baking
soda. Apply a light coating of grease to the battery
terminals to prevent corrosion.
Battery size: 12 v, 495 Cold Cranking Amps at 0 F.
Group size 45.
Checking the Electrolyte Level
1. Park the machine on a level surface. Disengage
the power take off (PTO), set the parking brake,
lower the attachment lift, and turn the ignition
key to “STOP” to stop the engine. Remove the
ignition key.
2. Open the hood.
POTENTIAL HAZARD
• Components under the hood will be hot if
the tractor has been running.
WHAT CAN HAPPEN
• Touching hot components can cause burns.
HOW TO AV
OID THE HAZARD
• Allow the tractor to cool before performing
maintenance or touching components
under the hood.
3. Lift off the cell cover to see into the cells. The
electrolyte must be up to the lower part of the
tube (Fig. 52). Do not allow the electrolyte to get
below the plates.
4. If the electrolyte is low, add the required amount
of distilled water; refer to Adding Water to the
Battery.
