Assembly
Loose
Parts
Note: Use the chart below to verify all parts have been shipped.
DESCRIPTION QTY. USE
Seat
Clamp
Washer
Capscrew
1
1
4
4
Install seat, page 10.
Steering Wheel
Roll Pin
Spacer
1
1
1
Install
steering wheel, page 9.
Key
2
Use in ignition and “key choice” switch
Capscrew, 1/4–20 x 3/4”
Wing Nut, 1/4 x 20
2
2
Secure
battery cables to battery
, page 10.
Hose Coupling
1
Connect
garden hose to washout port during
maintenance.
Operator‘s Manual
1 Read
manual before operating rider
.
Registration Card
1 Fill
out and mail to T
oro.
Hang Tag
1 Read
for warranty information.
