13
Operation
Operating
the Power T
ake Off
(PTO)
The power take off (PTO) switch engages and
disengages power to the electric clutch.
Engaging the PTO
1. Release pressure on the traction control levers
and place in neutral (Fig. 21).
2. Release the parking brake (Fig. 21).
m-3180
3
2
1
Figure 21
1. Traction
control lever
2.
Parking brake
3. PTO-Switch
3. To engage lift cover and move the PTO switch to
the “ON” position (Fig. 22).
Disengaging the PTO
1. Closing the cover moves the PTO switch to the
“OFF”position (Fig. 22).
m-2721
2
1
Figure 22
1. PTO-Off 2. PTO-On
