Hy draulic fluid escaping under pr essur e can
penetrate skin and cause injur y .
• If h y draulic fluid is injected into the skin
it must be surgicall y r emo v ed within a
few hour s by a doctor f amiliar with this
type of injur y . Gang r ene may r esult if
this is not done.
• K eep body and hands a w ay fr om pin hole
leaks or nozzles that eject high pr essur e
h y draulic fluid.
• Use cardboard or paper to find h y draulic
leaks.
• Safel y r eliev e all pr essur e in the h y draulic
system bef or e perf or ming an y w or k on
the h y draulic system.
• Mak e sur e all h y draulic fluid hoses
and lines ar e in good condition and
all h y draulic connections and fittings
ar e tight bef or e appl ying pr essur e to
h y draulic system.
Setting the Hydraulic Pump
Neutral Position
Note: Adjust the handle neutral first. T hat needs
to be cor rect before the follo wing adjustment can
be made .
T his adjustment m ust be made with dri v e wheels
tur ning .
Mechanical or h y draulic jacks may f ail to
suppor t machine and cause a serious injur y .
• Use jack stand when suppor ting
machine.
• Do not use h y draulic jacks.
Engine must be r unning so motion contr ol
adjustment can be perf or med. Contact with
mo ving par ts or hot surf aces may cause
per sonal injur y .
K eep hands, feet, f ace, clothing and other
body par ts a w ay fr om r otating par ts, muf fler
and other hot surf aces.
1. Raise the frame and bloc k up the mac hine so
dri v e wheels can rotate freely .
2. Disconnect the electrical connector from
the seat safety switc h. T emporaril y install
a jumper wire across ter minals in the wiring
har ness connector .
3. Unlatc h the seat and slide seat forw ard.
4. Disconnect the seat rod and tilt the seat fully
forw ard.
Setting the Left-hand Hydraulic Pump
Neutral Position
1. Star t the engine , open the throttle 1/2 w a y and
release parking brak e . R efer to Star ting and
Stopping the Engine in Operation , pag e 14 .
Note: T he motion control lev er m ust be in
neutral while making any adjustments .
2. Adjust the pump rod length b y rotating the
knob , in the appropriate direction, until the
wheel is still or slightly cree ping in rev erse
( Figure 58 ).
3. Mo v e the motion control lev er forw ard and
rev erse , then bac k to neutral. T he wheel m ust
stop tur ning or slightly cree p in rev erse .
4. Open the throttle to fast. Mak e sure wheel
remains stopped or slightly cree ps in rev erse ,
adjust if necessar y .
45
