SPECIFIC INFORMATIONS
– 13 –
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA
SAFETY INSTRUCTIONS
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
Table-1
Table-2
14"
HIGH VOLTAGE AT ZERO BEAM: (A) 24.5 kV
MAX HIGH VOLTAGE: (B) 25.0 kV
AC VOLTAGE (C) 110-240 V
RCUT R CUTOFF (B/W) 20H ←
GCUT G CUTOFF (B/W) 20H ←
BCUT B CUTOFF (B/W) 20H ←
GDRV G DRIVE 40H ←
BDRV B DRIVE 40H ←
BRTC SUB BRIGHT CEN 40H ←
COLC SUB COLOR CEN NTSC 30H ←
TNTC SUB TINT CEN 45H ←
COLP SUB COLOR CEN PAL 09H ←
COLS SUB COLOR CEN SECAM 30H ←
SCNT SUB CONTRAST 08H ←
HPOS 50Hz H-POSITION 0DH 13H
VPOS V-POSITION 04H ←
HIT HEIGHT 1EH 24H
VLIN V-LINEARITY 0AH ←
SBY SECAM R-Y 08H ←
SRY SECAM-B-Y 08H ←
RAGC RF AGC 2AH ←
Item
Adjustment Reference data
Data
To Next Page
