SPECIFIC INFORMATIONS
CHASSIS AND CABINET REPLACEMENT PARTS LIST
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRE-
CAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “
” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Model: 14C3E1/14C3ES1/14C3T1/14C2E1
Capacitors .......... CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............ CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Location Parts No. Description
No.
#1: [14C3E1]
#2: [14C3ES1]
#3: [14C3T1]
#4: [14C2E1]
CAPACITORS
C101 76794101 ELECTROLYTIC, 16V 100UF M
C102 76763221 ELECTROLYTIC, 16V 220UF M
C103 #1 76109103 CERAMIC CHIP, 50V B 0.01UF K
#2 76109103 CERAMIC CHIP, 50V B 0.01UF K
#4 76109103 CERAMIC CHIP, 50V B 0.01UF K
C104 #1 76105470 CERAMIC CHIP, 50V CH 47PF J
#2 76105470 CERAMIC CHIP, 50V CH 47PF J
#4 76105470 CERAMIC CHIP, 50V CH 47PF J
C106 76796479 ELECTROLYTIC, 35V 4.7UF M
C108 76795100 ELECTROLYTIC, 25V 10UF M
C111 #3 76105470 CERAMIC CHIP, 50V CH 47PF J
C112 #3 76105470 CERAMIC CHIP, 50V CH 47PF J
C113 76109102 CERAMIC CHIP, 50V B 1000PF K
C114 76109102 CERAMIC CHIP, 50V B 1000PF K
C118 76109102 CERAMIC CHIP, 50V B 1000PF K
C120 76203100 ELECTORLYTIC, 16V 10UF M
C121 76109103 CERAMIC CHIP, 50V B 0.01UF K
C123 76206010 ELECTROLYTIC, 50V 1UF M
C129 76109102 CERAMIC CHIP, 50V B 1000PF K
C130 76797479 ELECTROLYTIC, 50V 4.7UF M
C131 76814103 CERAMIC CHIP, 50V F 0.01UF Z
C132 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C133 76105101 CERAMIC CHIP, 50V CH 100PF J
C135 76109222 CERAMIC CHIP, 50V B 2200PF K
C136 76206228 ELECTROLYTIC, 50V 0.22UF M
C137 76100103 CERAMIC CHIP, 50V F 0.01UF Z
C138 76794470 ELECTROLYTIC, 16V 47UF M
C141 76105101 CERAMIC CHIP, 50V CH 100PF J
C150 #1 76814103 CERAMIC CHIP, 50V F 0.01UF Z
#2 76814103 CERAMIC CHIP, 50V F 0.01UF Z
#4 76814103 CERAMIC CHIP, 50V F 0.01UF Z
C166 76109103 CERAMIC CHIP, 50V B 0.01UF K
C167 76794101 ELECTROLYTIC, 16V 100UF M
C170 76109103 CERAMIC CHIP, 50V B 0.01UF K
C171 #1 76203100 ELECTORLYTIC, 16V 10UF M
#2 76203100 CAPACITOR, ELECTORLYTIC, 16V 10UF M
#4 76203100 ELECTORLYTIC, 16V 10UF M
C172 #1 76203100 ELECTORLYTIC, 16V 10UF M
#2 76203100 ELECTORLYTIC, 16V 10UF M
#4 76203100 ELECTORLYTIC, 16V 10UF M
C173 #1 76203100 ELECTORLYTIC, 16V 10UF M
#2 76203100 ELECTORLYTIC, 16V 10UF M
#4 76203100 ELECTORLYTIC, 16V 10UF M
C174 76105330 CERAMIC CHIP, 50V CH 33PF J
C175 76105330 CERAMIC CHIP, 50V CH 33PF J
C176 76105330 CERAMIC CHIP, 50V CH 33PF J
C179 #3 76109103 CERAMIC CHIP, 50V B 0.01UF K
C180 #3 76109103 CERAMIC CHIP, 50V B 0.01UF K
C189 76206478 ELECTROLYTIC, 50V 0.47UF M
C192 76206478 ELECTROLYTIC, 50V 0.47UF M
C216 76206010 ELECTROLYTIC, 50V 1UF M
C221 76105101 CERAMIC CHIP, 50V CH 100PF J
C222 76105101 CERAMIC CHIP, 50V CH 100PF J
C223 76105101 CERAMIC CHIP, 50V CH 100PF J
C224 76203100 ELECTORLYTIC, 16V 10UF M
C226 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C227 76100104 CERAMIC CHIP, 25V F 0.1UF Z
C234 76109103 CERAMIC CHIP, 50V B 0.01UF K
C235 76109103 CERAMIC CHIP, 50V B 0.01UF K
C305 76617915 ELECTROLYTIC, 50V 1UF K
C306 76794102 ELECTROLYTIC, 16V 1000UF M
C307 76693473 PLASTIC FILM, 100V 0.047UF J
C308 76765101 ELECTROLYTIC, 35V 100UF M
C309 76203100 ELECTORLYTIC, 16V 10UF M
C312 76796102 ELECTROLYTIC, 35V 1000UF M
C313 76082280 PLASTIC FILM, 100V 0.22UF J
C314 76212152 CERAMIC DISC, 50V B 1500PF K
C315 76503049 PLASTIC FILM, 63V 0.47UF J
C317 76214471 CERAMIC DISC, 500V B 470PF K
C320 76765101 ELECTROLYTIC, 35V 100UF M
C410 76693472 PLASTIC FILM, 100V 4700PF J
C417 76214102 CERAMIC DISC, 500V B 1000PF K
C420 76794220 ELECTROLYTIC, 16V 22UF M
C421 76794470 ELECTROLYTIC, 16V 47UF M
C431 76797479 ELECTROLYTIC, 50V 4.7UF M
C432 76203100 ELECTORLYTIC, 16V 10UF M
C433 76100103 CERAMIC CHIP, 50V F 0.01UF Z
C434 76100103 CERAMIC CHIP, 50V F 0.01UF Z
C435 76763471 ELECTROLYTIC, 16V 470UF M
C436 76206478 ELECTROLYTIC, 50V 0.47UF M
C437 76109822 CERAMIC CHIP, 50V B 8200PF K
C438 76100103 CERAMIC CHIP, 50V F 0.01UF Z
C439 76105470 CERAMIC CHIP, 50V CH 47PF J
C440 76503264 PLASTIC FILM, 1250VH 7200PF H
C442 76082994 PLASTIC FILM, 250V 0.3UF J
C445 76693104 PLASTIC FILM, 100V 0.1UF J
C446 76679100 ELECTROLYTIC, 250V 10UF M
C448 76678220 ELECTROLYTIC, 200V 22UF M
C449 76763471 ELECTROLYTIC, 16V 470UF M
C463 76109152 CERAMIC CHIP, 50V B 1500PF K
C484 #1 76591104 PLASTIC FILM, 50V 0.1UF J
#2 76591104 PLASTIC FILM, 50V 0.1UF J
