6. When the printer is properly latched into place, verify that the printer does not move up and
down. Also confirm that the printer is securely attached to the wall.
To remove the printer from the wall mounting bracket:
1.
Press and hold the release latch
B (see Figure 4 ).
2. While pressing the release latch, lift the printer up and off the wall mounting bracket.
Configuring the paper low sensor for wall mounting
When mounting the printer to the wall, you will need to configure the printer before using.
Note: The printer only has to be configured when it is first mounted to the wall.
To configure the paper low sensor, flick the small gray paper low sensor tab A using a sharp,
flat instrument (such as a screwdriver) to rotate it from the "H" position to the "WALL" position
(see Figure 5
).
Figure 5. Rotation of paper low sensor
Installing an optional interface adapter card
There is an option slot on the back of the Toshiba TCx Single Station printer that can extend the
functionality of the base printer. The optional interface adapter card can be either an Ethernet,
WiFi, or RS-232 interface adapter card.
14 TCx Single Station Printer Installation and Service Guide
