Data Transmission
IrDA
1. Place the printer close to the host so that their IrDA
windows face each other within a 20 cm distance.
2. Turn on the printer and the host and send data
from the host to the printer.
NOTE:
While communicating, avoid locations where the IrDA
window is subjected to direct sunlight. A
communication failure may occur.
• To communicate with the host via IrDA, it is
required to configure the printer settings on the
host.
• The communicable distance and angle are shown
in the figure on the right. Note that this
performance is obtained under 1000 lux or less of
fluorescent lamp light.
USB
1. Turn on the host and start the system.
2. Turn on the printer and connect a USB cable to the
printer.
3. Connect the USB cable to the host.
4. Send data from the host to the printer.
NOTE:
•
For details of the interface cable, consult the
nearest Toshiba Tec representative.
•
When disconnecting the USB cable, follow the
instructions of the system on the host.
0cm
terminal
Printer
cable
port
Printer
Approx. 20 mm
Host
When connecting a USB cable or an RS-232C cable to the printer, put the ferrite core supplied with the
printer on the cable as shown below.
Wind the cable around
the ferrite core one time.
°
°
To Next Page
