Toshiba B-EP4DL-GH32-QM-R User Manual

19
Printer Specification
Model B-EP4DL-GH20-QM-R B-EP4DL-GH32-QM-R B-EP4DL-GH42-QM-R
Driving power source
 Lithium ion battery 14.8V, 2600 mAh (Nominal value) (Battery pack model
name: B-EP804-BT-QM-R)

Lithium ion battery 14.8V, Nominal 2600 mAh, Rated 2450 mAh (Battery pack
model name: 4-18650Z (B-EP804-BT-QM-R))
Printable count
Approx.100m/Full charge
(It depends on the operating environment, print conditions, battery condition, etc.)
Life cycle
300 cycles
Print method
Direct thermal
Resolution
8 dots/mm (203 dpi)
Print speed
Max. 105.0 mm/sec.
(It depends on the operating environment, print conditions, battery condition, etc.)
Issue mode
Peel-off, Batch
Effective print width
Max. 104.0 mm
Font
[Bitmap font]
Times Roman, Helvetica, Presentation, Letter Gothic, Prestige Elite, Courier, OCR-
A,
OCR-B, GOTHIC725 Black, Standard character
, Bold character, Price font 1,
Price font 2, Chinese character, Writable character
[Outline font]
Helvetica (w/wo proportional), Price font 1, Price font 2, Price font 3
Barcode
JAN8/EAN8, JAN13/EAN13, UPC-A/E, CODE39, CODE93, CODE128/EAN128, MSI
,
NW-7, ITF, Customer barcode,
GS1 Databar (Omnidirectional/Truncated/Stacked/Stacked Omnidirectional/Limited/
Expanded/Expanded Stacked)
2-dimensional code
QR code, Data Matrix, PDF417, Maxicode, MicroPDF417
Media detection sensor
Transmissive, Reflective, Peel-off
Interface
IrDA (IrDA V1.2 Low power)
Available
Available
Available
USB (V2.0)
Available
Available
Available
RS-232C
Available
---
---
Bluetooth
---
V2.1+EDR
---
Wireless LAN
---
---
IEEE802.11a/b/g/n
Operating temperature
-15ºC to 50ºC
0ºC to 50ºC
- During battery charge: 0ºC to 40ºC
- LCD display: 0ºC to 50ºC
Operating humidity
10%RH to 90%RH (No condensation)
Storage temperature
-25ºC to 60ºC
Storage humidity
10%RH to 90%RH (No condensation)
Dimensions (Unit: mm)
150.0 (W) x 145.0 (L) x 75.0 (D) (Excluding the projecting parts)
Weight
B-EP4DL-GH20-QM-R, B-EP4DL-GH32-QM-R: Approx. 860 g
B-EP4DL-GH42-QM-R: Approx. 890 g
(Battery pack included, media and other accessories excluded)
Accessories
Battery pack (1pc.), Print head cleaner (1 pc.), Belt clip (1 pc.), Belt clip mounting
screw (2 pcs.), Ferrite core (1 pc.), Owner’s Manual (1 pc.), BD Address label (2 pcs.)
(B-EP4DL-GH32-QM-R)
Options
1-slot battery charger (B-EP800-CHG-QM-R), 6-slot battery charger (B-EP800-
CHG6-QM-R), AC adapter (B-FP800-AC-QM-S), Battery pack (B-EP804-BT-QM-
R),
Shoulder strap (B-EP900-SS-QM-R)
Supplement
Specification of this printer may be changed without prior notice.
