29
Loading the Media
1. Press the Top Cover Open Button to open the Top
Cover.
2. Move the Paper Guide Lever toward the Operation
Panel and the Paper Guides outward.
NOTE:
Do not move the Paper Guides without unlocking
the Paper Guide Lever. Doing this may break the
Paper Guide.
3. Place a media roll in the printer. Only outside
wound media can be used in the printer.
4. Adjust the Paper Guides to the media roll width.
5. Push back the Paper Guide Lever to lock the Paper
Guides.
6. Pull the top edge of the media toward the Operation
Panel, and close the Top Cover removing slack of
the media.
NOTE:
Please use TOSHIBA TEC approved media only.
Toshiba TEC is not responsible for any print result
caused by use of other media
When you order media, please contact the nearest
TOSHIBA TEC representative.
Top Cover
Open Button
Top Cover
Paper Guide
Lever
Pape
Guide
Release
Media
Top Cover
Paper Guide
Lever
Paper Guide
Lock
To Next Page
