General Specifications
(*1) 3tap is not supported * Underbar is factory default
(*2) 83MHz / 3tap setting
(*3) 83MHz / 2tap setting
Model Name
BC040M
BC160M
Imager
CMOS image sensor
Maximum number of Video out pixels
(H) x (V)
720×540
1440×1080
Optical Size
1/2.9 type
1/2.9 type
Scanning area (H) x (V) [mm]
5.02×3.82
5.00×3.75
Pixel size (H) x (V) [μm]
6.90×6.90
3.45×3.45
Scan method
Progressive
Electronic shutter method
Global shutter
Aspect ratio
4:3
Sensitivity
2700lx, F11, 1/125s
2600lx, F11, 1/31s
Minimum illuminance
F1.4, Gain +24dB, Video level 50%
2lx
2lx
Power supply
PoCL
DC+12V ±10% (From CameraLink connector )
Power consumption
(at all pixels readout)
PoCL
1.6W(max)
1.7W(max)
Interface
CameraLink Base Configuration
Transmission speed
37.5 / 50 / 83 MHz x 1 / 2 / 3 tap
Image output format
Mono8 / Mono10
(*1)
/ Mono12
(*1)
Maximum Frame rate (at all pixels readout)
Mono8
(*2)
HighFramerateMode=OFF
436 fps
148 fps
HighFramerateMode=ON
523 fps
非対応
Mono10
(*3)
/ Mono12
(*3)
320 fps
Incompatible
Dimensions
29 mm(W) x 29 mm (H) x 26.5 mm (D) (Not including protrusion)
Mass
Approximately 33g
Lens mount
C mount
Flange back
17.526mm
Camera body grounding insulation status
Conductive between circuit GND and camera body
