Toshiba BC Series User Manual

26 / 73
Copyright © 2019 Toshiba Teli Corporation, All Rights Reserved. http://www.toshiba-teli.co.jp/en/
D4296087A
Register Map
BC series has GenCP and Legacy protocol as command communication protocol.
IIDC2 Address
The following address is possible to control by GenCP and Legacy protocol.
Register
address
Read
Write
AC(*)
Memory
save
Default
Register name
Description
0x0020 005C
R.O.
-
-
0x0
ApplyImageFormat
0x0:No error, 0x10:Scalable setting error
0x0020 105C
R/W
✓
✓
0x1
CameraLink Tap
0x1:1Tap,0x2:2Tap,0x3:3Tap
0x0020 107C
R/W
✓
✓
0x32
CameraLink CLK
0x25:37.5000MHz,0x32:50.0000MHz,0x53:83.0357MHz
0x0020 2094
R/W
✓
✓
0x0
offsetX
Scalable: Horizontal offset (in pixels) from the origin to the region of interest
0.4M:0x0 (0) ～ 0x290 (656) OffsetX setting unit: 4
1.6M:0x0 (0) ～ 0x560 (1376) OffsetX setting unit: 4
0x0020 2098
R/W
✓
✓
0.4M:0x2D0
1.6M:0x5A0
Width
Scalable: Width
0.4M:0x40 (64) ～ 0x2D0 (720) Width setting unit: 4
1.6M:0x40 (64) ～ 0x5A0 (1440) Width setting unit: 4
0x0020 209C
R/W
✓
✓
0x0
offsetY
Scalable: Vertical offset (in pixels) from the origin to the region of interest.
0.4M:0x0 (0) ～ 0x1DC (476) OffsetY setting unit: 2
1.6M:0x0 (0) ～ 0x3F8 (1016) OffsetY setting unit: 2
0x0020 20A0
R/W
✓
✓
0.4M:0x21C
1.6M:0x438
Height
Scalable: Height
0.4M:0x40 (64) ～ 0x21C (540) Height setting unit: 2
1.6M:0x40 (64) ～ 0x438 (1080) Height setting unit: 2
0x0020 303C
R/W
-
-
0x8
Acquisition
Command
0x0: Abort image output. 0x1: Stop image output.
0x8: Start image output.
0x0020 30A8
R/W
-
✓
0x0
Acquisition
FrameRateControl
0x0:NoSpecify Take priority ExposureTime setting.
0x1:Manual Take priority AcquisitionFrameRate setting.
0x0020 30BC
R/W
-
✓
0.4M:0x736F31
1.6M:0x1E517F
Acquisition
FrameRate
Framerate
*AcquisitionFrameRate / 65536[fps]
0x0020 30C8
R/W
-
✓
0x0
Aqcuisition
FrameIntervalControl
0x0:NoSpecify Take priority ExposureTime setting.
0x1:Manual Take priority AcquisitionFrameRate setting.
0x0020 30DC
R/W
-
✓
0.4M:0x4F4FB
1.6M:0x12DF8A
Acquisition
FrameInterval
Interval
*AcquisitionFrameInterval / 37500000[sec]
0x0020 4028
R/W
-
✓
0x1
ExposureTimeControl
0x0:NoSpecify Take priority AcquisitionFrameRate setting.
0x1:Manual Take priority ExposureTime setting.
0x0020 403C
R/W
-
✓
0.4M:0x493E0
1.6M:0x124F80
ExposureTime
ExposureTime
ShortExposureMode=OFF:
*ExposureTime / 37500000 [sec]
0x22B (14.8usec) ～ 0x23C34600 (16sec)
ShortExposureMode=ON:
*ExposureTime * 53 / 983850009 [sec]
0x14 (1.1usec) ～ 0xF7 (13.3usec)
0x0020 405C
R/W
-
✓
0x0
BlackLevel
0xFFFFFFEFF (-25%) ～ 0x100(+25%)
0x0020 407C
R/W
-
✓
0x0
Gain
0x0 (0dB) ～ 0xF0 (24dB)
0x0020 409C
R/W
-
✓
0x64
Gamma
Min:0x2D(γ=0.45) Max:0x64(γ=1.0)
0x0020 439C
R/W
-
✓
0x0
ShortExposureMode
0x0:OFF,0x1:ON
0x0020 603C
R/W
-
✓
0x0
LUT Enable
0x0:OFF,0x1:ON
0x0030 0000
R/W
-
-
0x0
LUTValue[0]
Min:0x0,MAX:0xFFF
0x0030 0004
LUTValue[1]
↓
↓
0x0030 0FFC
LUTValue[1023]
↓
↓
0x0030 3FFC
LUTValue[4095]
