● Control procedure
■ HighFramerateMode
IIDC2 address
Before write to HighFramerateMode (0x0021 F59C), stop image output (Write to 0x00 to
AcquistionCommand (0x0020 303C)). After change setting of PixelSize, restart image output (Write to
0x08 to AcquistionCommand (0x0020 303C)).
Notes on HighFramerateMode:
- If you use HighFramerateMode, improves frame rate and sensitivity by about 4 times, but image quality may
deteriorate. Also, the actual exposure time may vary depending on the individual differences and the operating
environment (such as the operating temperature).When using the HighFramerateMode, I ask you to have final image
quality checked with your environment.
