Installing the USB Driver 17
Installing the USB Driver
Never turn the power off of the equipment or pull out the USB cable while you are installing the
e-STUDIO163/203/165/205 software and data communication is being performed between the
equipment and your PC.
From the Plug-and-Play Prompt
When using the e-STUDIO163/203/165/205 is connected to your PC via the USB cable and
powered on Windows will prompt to install drivers for the new hardware.
Drivers are provided on the CD in the "Driv_USB" folder, select to install drivers from this spe-
cific location.
These drivers will install an additional COM port, in Windows through which the Toshiba Viewer
will then communicate with the e-STUDIO163/203/165/205. There are various ways of installa-
tion according to the Windows version running on your PC.
P.17 “Windows 98 SE/Me”
P.23 “Windows 2000”
P.28 “Windows XP/Server 2003”
Windows 98 SE/Me
The following describes an installation on Windows 98 Second Edition.
The procedure is almost the same when Windows Me is used.
Make sure you understand the following information.
An additional COM port can only be installed on your PC by your executing USB driver installa-
tion two times. Even if you finish the installation by clicking the [Finish] button on the “Add New
Hardware Wizard”, the communication port will not be installed. When the “Add New Hardware
Wizard” appears again after clicking the [Finish] button, follow the procedure in the manual to
execute the USB driver installation once again.
1
Connect the e-STUDIO163/203/165/205 to the computer by a USB
cable, make sure it is turned on and start Windows.
To Next Page
