44-EN43-EN
– 2 2 –
Table 2
Equivalent
HP
Model name of
outdoor unit
MMY-
Combination of outdoor unit
MMY-
Corrective of
refrigerant
(kg)
Unit 1 Unit 2 Unit 3
8HP MAP0806* MAP0806* - - 2
10HP MAP1006* MAP1006* - - 3
12HP MAP1206* MAP1206* - - 8
14HP MAP1406* MAP1406* - - 10
16HP MAP1606* MAP1606* - - 12
18HP MAP1806* MAP1806* - - 14
20HP MAP2006* MAP2006* - - 15
22HP AP2216* MAP1206* MAP1006* - 6
24HP AP2416* MAP1406* MAP1006* - 8
26HP AP2616* MAP1406* MAP1206* - 12
28HP AP2816* MAP1406* MAP1406* - 12
30HP AP3016* MAP1606* MAP1406* - 14
32HP AP3216* MAP1806* MAP1406* - 15
34HP AP3416* MAP1806* MAP1606* - 16
36HP AP3616* MAP1806* MAP1806* - 18
38HP AP3816* MAP2006* MAP1806* - 22
40HP AP4016* MAP2006* MAP2006* - 24
42HP AP4216* MAP1406* MAP1406* MAP1406* 14
Charging of refrigerant
• Keeping the valve of the outdoor unit closed, be sure to charge the liquid refrigerant into the service port at the
liquid side.
• If the specified amount of refrigerant cannot be charged, fully open the valves of the outdoor unit at liquid and
gas sides, operate the air conditioner in COOL mode, and then charge refrigerant into service port at the gas
side. In this time, choke the refrigerant slightly by operating the valve of the canister to charge liquid refrigerant.
• The liquid refrigerant may be charged suddenly, therefore be sure to charge refrigerant gradually.
Adding refrigerant
After finishing vacuuming, exchange the vacuum pump with a refrigerant canister and start additional charging of
refrigerant.
Calculation of additional refrigerant charge amount
Refrigerant charge amount at shipment from the factory does not include the refrigerant for pipes at the local site.
For refrigerant to be charged in pipes at the local site, calculate the amount and charge it additionally.
NOTE
If the additional refrigerant amount indicates minus as the result of calculation, use the air conditioner without
additional refrigerant.
Outdoor unit type MAP080 MAP100 MAP120 MAP140 MAP160 MAP180 MAP200
Charging amount (kg) 11.0
Additional refrigerant
charge amount at local site
=
Real length of liquid pipe
×
Additional refrigerant
charge amount per 1 m
liquid pipe (Table 1)
×
1.3
+
Corrective amount of
refrigerant depending on HP
of co-operating outdoor units
(Table 2)
Table 1
Liquid pipe dia. (mm) 6.4 9.5 12.7 15.9 19.1 22.2
Additional refrigerant amount / 1 m
liquid pipe (kg/m)
0.025 0.055 0.105 0.160 0.250 0.350
