User’s Manual G-3
TOSHIBA PC Health Monitor
Cleaning the cooling module
This section explains how to clean the Cooling module.
To clean the cooling module, follow the steps as detailed below:
1. Shut down the computer - make sure the Power indicator is off (refer to
the Turning off the power section in Chapter 1, Getting Started if
required).
2. Remove the AC adaptor and all cables and peripherals connected to
the computer.
3. Remove the battery pack (refer to the Replacing the battery pack
section in Chapter 6, Power and Power-Up Modes, if required).
4. Open the display panel.
5. Slip your finger under a notch at the end of the keyboard brace and lift
up to release latches and remove the keyboard brace.
Figure G-1 Removing the keyboard brace
6. Remove three screws and the metal fittings securing the keyboard.
Figure G-2 Removing the screws and metal fittings
1. Keyboard barce
1. Screws
2. Metal fittings
To Next Page
