User’s Manual 2-7
The Grand Tour
Front with the display open
This section shows the computer with the display panel open. In order to
open the display, lift the display panel up and position it at a comfortable
viewing angle for you.
Figure 2-6 The front of the computer with the display open
1. Web Camera LED 9. Touch Pad On/Off button
2. Web Camera 10. Touch Pad control buttons
3. Wireless LAN antennas (Not shown) 11. Touch Pad
4. Front operation panel (seven panels) 12. LCD Sensor switch (Not shown)
5. Stereo speakers 13. Power button
6. Bluetooth antenna (Not shown) 14. Display hinge
7. Microphone 15. Display screen
8. System indicators
