J POWER SOURCE (Current Flow Chart)
Driver Side J/B (See Page 24)
Fuse System Page
7.5A ACC
Air Conditioning
Audio System (10 Speaker)
Audio System (6 Speaker)
Automatic Light Control
Door Lock Control
Engine Control (1GR–FE)
Engine Control (2UZ–FE)
Headlight
Interior Light
Key Reminder
Light Auto Turn Off System
Multiplex Communication System (BEAN)
Navigation System, Parking Assist (Rear View Monitor) and
Audio System (w/ Navigation System)
Power Outlet (12V)
Power Window
Rear Window Defogger and Mirror Heater
Rear Wiper and Washer
Remote Control Mirror
Seat Belt Warning
Shift Lock
Theft Deterrent
Wireless Door Lock Control
358
342
348
140
202
84
70
130
154
176
142
104
334
298
192
330
186
294
178
292
222
212
7.5A GAUGE
ABS, TRAC, VSC, Auto LSD, Downhill Assist Control and
Hill–Start Assist Control
Active Height Control Suspension and
Electric Modulated Air Suspension
Air Conditioning
Audio System (10 Speaker)
Audio System (6 Speaker)
Charging
Combination Meter
Cruise Control (1GR–FE)
Cruise Control (2UZ–FE)
Door Lock Control
Electronically Controlled Transmission and A/T Indicator (1GR–FE)
Electronically Controlled Transmission and A/T Indicator (2UZ–FE)
Engine Control (1GR–FE)
Engine Control (2UZ–FE)
Interior Light
Key Reminder
Moon Roof
Multi Mode 4WD
Multiplex Communication System (BEAN)
258
268
358
342
348
68
352
252
246
202
238
230
84
70
154
176
288
274
104
∗ These are the page numbers of the first page on which the related system is shown.
