Toyota 4RUNNER 2007 - Engine Control for 1 GR-FE - Parts Location

96
4RUNNER (EM03M0U)
Engine Control for 1GR–FE
: Parts Location
Code See Page Code See Page Code See Page
A11 34 (1GR–FE) I3 35 (1GR–FE) J34 B 38
A12 34 (1GR–FE) I4 35 (1GR–FE) J37 38
A13 34 (1GR–FE) I5 35 (1GR–FE) J40 A 40
A16 A 36 I6 35 (1GR–FE) J41 B 40
A17 B 36 I9 35 (1GR–FE) J47 A 38
A24 36 I10 35 (1GR–FE) J48 B 38
A32 36 I11 35 (1GR–FE) J49 C 38
C2 34 (1GR–FE) I12 35 (1GR–FE) J50 D 38
C3 34 (1GR–FE) I13 35 (1GR–FE) J51 E 38
C4 A 34 (1GR–FE) I14 35 (1GR–FE) J52 F 38
C8 A 37 I18 37 K1 35 (1GR–FE)
C9 B 37 J2 A 35 (1GR–FE) K2 A 35 (1GR–FE)
C10 C 37 J3 B 35 (1GR–FE) L4 40
D1 37 J4 38 M1 A 35 (1GR–FE)
E2 34 (1GR–FE) J5 38 P1 35 (1GR–FE)
E4 A 37 J7 38 P2 35 (1GR–FE)
E5 B 37 J8 A 38 S11 39
E6 C 37 J9 B 38 S12 39
E7 D 37 J16 38 S28 35 (1GR–FE)
E8 E 37 J18 38 T2 35 (1GR–FE)
F8 34 (1GR–FE) J22 38 T8 39
F9 A 37 J27 38 V1 A 35 (1GR–FE)
F10 B 37 J28 38 V2 A 35 (1GR–FE)
F14 40 J29 A 38 V3 A 35 (1GR–FE)
H6 34 (1GR–FE) J30 B 38 V4 A 35 (1GR–FE)
H8 34 (1GR–FE) J31 A 38 Y1 39
I1 35 (1GR–FE) J32 B 38
I2 35 (1GR–FE) J33 A 38
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1C
24
Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
1D
24
Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
1E
24
Engine Room Main Wire and Driver Side J/B (Lower Finish Panel)
1G
25
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
1H
25
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
1J
25
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
1K
25
Instrument Panel Wire and Driver Side J/B (Lower Finish Panel)
1L
3C
28
Instrument Panel Wire and Center J/B (Instrument Panel Brace RH)
3D
28
Instrument Panel Wire and Center J/B (Instrument Panel Brace RH)
3E
28
Instrument Panel Wire and Center J/B (Instrument Panel Brace RH)
