TP-Link AC1200 User Manual

32
Chapter 6 Parental Controls
Control the times of day my children or other home network
users are allowed to access the Internet and even types of
websites they can visit.
For example, I want to allow my children’s devices (e.g. a computer
or a tablet) to access only
www.tp-link.com and Wikipedia.org
from 18:00 (6PM) to 22:00 (10PM) at the weekend and not other
times.
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or
the password you set for the router.
2. Go to
Advanced > Parental Controls and enable Parental
Controls
.
3. Click Add. And then Click View Existing Devices, and select
the access device. Or, input the
Device Name and MAC
Address
manually.
4. Click the icon to set the Internet Access Time. Drag the
cursor over the appropriate cell(s) and click
OK.
I want to:I want
How can I
do that?

TP-Link AC1200 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
