TP-Link AC1200 User Manual

66
Chapter 11 Manage the Router
11. 1. Set Up System Time
System time is the time displayed while the router is running. The system time you
configure here will be used for other time-based functions like Parental Controls. You
can choose the way to obtain the system time as needed.
1. Visit
http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to
Advanced > System Tools > Time Settings.
¾ To get time from the internet:
1. In the
Set Time field, select Get automatically from the Internet.
2. Select your local Time Zone from the drop-down list.
3. In the NTP Server I fileld, enter the IP address or domain name of your desired NTP
Server.
4. (Optional) In the
NTP Server II fileld, enter the IP address or domain name of the
second NTP Server.
5. Click
Obtain to get the current Internet time and click Save.
¾ To manually set the date and time:
1. In the
Set Time field, select Manually.

TP-Link AC1200 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
