TP-Link Archer A10 User Manual

42
Chapter 10
Network Security
How can I do that?
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to
Advanced > Security > IP & MAC Binding.
3. Enable ARP Binding.
4. Bind your device(s) according to your need.
To bind the connected device(s):
Click
to add the corresponding device to the Binding List.
To bind the unconnected device:
1 ) Click
Add in the Binding List section.
2 ) Enter the MAC address and IP address that you want to bind. Enter a Description
for this binding entry.
3 ) Tick the
Enable This Entry checkbox and click OK.
Done! Now you don’t need to worry about ARP spoofing and ARP attacks!

TP-Link Archer A10 Specifications

General

Output current	1.5 A
Output voltage	12 V
Power source type	DC
Product type	Tabletop router
On/off switch	Yes
Product color	Black
LED indicators	LTE, Link, Power
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	3
3G	-
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	64-bit WEP, 128-bit WEP, SSID, WEP, WPA, WPA-PSK, WPA2
Switching protocols	IPv4, IPv6
Certification	FCC, CE, RoHS, RCM, IC, NCC, BSMI
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP

Weight and Dimensions

Depth	164 mm
Width	216 mm
Height	36.8 mm
