TP-Link Omada EAP235-Wall User Manual

67
3.1 Monitor the EAP
To monitor the EAP information, go to the Status > Device page.
The following device information is displayed:
Device Name Displays the name of the EAP. The name consists of the product model
followed with the MAC address of the EAP by default.
Device Model Displays the product model of the EAP.
Firmware Version Displays the current firmware version the EAP. To update the firmware,
you can refer to
5.6 Update the Firmware
.
Hardware Version Displays the hardware version the EAP.
MAC Address Displays the MAC address of the EAP.
IP Address Displays the IP address of the EAP.
Subnet Mask Displays the subnet mask of the EAP.
System Time Displays the current system time. To configure the system time, you can
refer to
5.3 Configure the System Time
.
Uptime Displays how long the EAP has been working since it starts up.

TP-Link Omada EAP235-Wall Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	4
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SSH, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-Enterprise, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Placement	Wall
Product color	White
LED indicators	LAN, Power, Status, WAN, WLAN
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	4 dBi
Power source type	PoE
Power consumption (typical)	24.4 W
Power over Ethernet (PoE) type supported	Active PoE, Passive PoE
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package type	Box
Package depth	184 mm
Package width	117 mm
Package height	33 mm
Package weight	300 g
Number of products included	1 pc(s)
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Virtual LAN features	Port-based VLAN, VLAN mapping
Transmitting power (CE)	20 - 23 dBm
Transmitting power (FCC)	21 dBm
Harmonized System (HS) code	85176990
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10

Weight and Dimensions

Depth	20 mm
Width	143 mm
Height	86 mm
