Electrical
Data
Tab. 05 - Electrical Data - 60 Hz
Nominal
Modelos
Components
Consumption
Rated
Start
Rated
Start
Rated
Start
(kW)
Current (A)
Current (A)
Current (A)
Current (A)
Current (A) Current (A)
Compressors
18,9 63,60 36,7 31,80
CGAD020
Fans
1,5 9,00 306,0 5,2 177,0 4,50 153,0
Total
20,4 72,60 41,9 36,30
Compressors
24,4 75,80 43,7 37,90
CGAD025
Fans
2,3 13,50 350,0 7,8 202,0 6,80 175,0
Total
26,7 89,30 51,5 44,70
Compressors
28,7 92,20 53,2 46,10
CGAD030
Fans
2,3 13,50 440,0 7,8 254,0 6,80 220,0
Total
31,0 105,70 61,0 52,90
Compressors
39,3 130,80 75,5 65,40
CGAD040
Fans
3,0 18,00 382,0 10,4 220,0 9,00 191,0
Total
42,3 148,80 85,9 74,40
Compressors
48,1 150,00 86,6 75,00
CGAD050
Fans
4,5 27,00 438,0 15,6 253,0 13,50 219,0
Total
52,6 177,00 102,2 88,50
Compressors
57,7 184,80 106,6 92,40
CGAD060
Fans
4,5 27,00 547,0 15,6 316,0 13,50 274,0
Total
62,2 211,80 122,2 105,90
Compressors
71,3 224,20 129,4 112,10
CGAD070
Fans
4,5 27,00 485,0 15,6 280,0 13,50 243,0
Total
75,8 251,20 145,0 125,60
Compressors
80,3 250,40 144,5 125,20
CGAD080
Fans
6,0 36,00 540,0 20,8 312,0 18,00 270,0
Total
86,3 286,40 165,3 143,20
Compressors
88,8 283,20 163,4 141,60
CGAD090
Fans
6,0 36,00 645,0 20,8 372,0 18,00 323,0
Total
94,8 319,20 184,2 159,60
Compressors
102,8 238,08 144,3 119,04
CGAD100
Fans
6,6 39,00 718,0 21,0 434,0 16,80 356,0
Total
109,4 277,08 165,3 135,84
Compressors
130,2 325,44 177,6 149,28
CGAD120
Fans
8,8 52,00 828,0 28,0 456,0 22,40 372,0
Total
139,0 377,44 205,6 171,68
Compressors
154,2 357,12 216,5 178,56
CGAD150
Fans
11,0 65,00 863,0 35,0 520,0 28,00 427,0
Total
165,2 422,12 251,5 206,56
60 Hz
220V 380V 440V
Notes:
(1) These values comply with operation conditions from ARI-590-92.
(2) When dimensioning feeding cables and components, consider a
30%-increment in these nominal values.
(3) Starting current values represent the sum of the starting current
from the last compressor to enter operation and the nominal currents of
other compressors and fans.
