8 AFDK-SVU01C-EN
Drive and Cabinet
Enclosure Rating
The Trane
®
cabinet has a NEMA 1 enclosure rating:
NEMA 1: Vented. Intended for general-purpose indoor
applica
tions.
Environmental Conditions
Important: Location of the AFDK is important if proper
performance and normal operating life is to
be expected. Therefore, unless designed for
special environments, the controller should
be installed in an area where the following
conditions exist.
• Verify that NEMA 1 enclosure is installed where it can
be kept clean an
d dry, away from oil, coolants, or other
airborne contaminants. The enclosure must be
installed in a non-corrosive location.
• The area chosen should allow the space required for
proper air flow. Adequate clearance for air circulation
around the enclosure is a 6 inch (15.25 cm) minimum
clearan
ce required wherever vents are located in the
cabinet.
• The area chosen should allow for service clearance in
front of the enclosure. Three feet (0.91 m) is
recommended for door swing and working space;
more space may be required by local building codes or
for service equipment, such as hoists used for drive
replacement. Because codes and equipment may vary,
determine the amount of space required for each
specific installation.
• Do not install the drive over 1000 meters (3300 feet)
above se
a level without derating output power. For
every 91.4 meters (300 feet) over 1000 meters
(3300 feet)
above sea level, derate the output current
1 percent.
• Line frequency is 60 Hz.
• Line voltage is 460 or 480 volts; variation must be
within
+10 percent.
• Verify that the drive location will meet the
environmen
tal conditions specified in Table 1.
Identifying Trane AFDK Cabinet
Components
The Trane AFDK cabinets have the following main
components. Ref er to Figure 1, p. 9 and Figure 2, p. 11 for
Frame 3, and Figure 3, p. 12, Figure 4, p. 13 and Figure 5,
p. 15 for Frame 4.
Drive Cabinet Component
Locations
Frame 3 Units (405, 600 A)
The main drive components for a Frame 3 unit are listed
below. Each numbered item corresponds to a number in
Figure 1.
1. Circuit Breaker, 600 V
2. Circuit Breaker Operating Mechanism
3. Inductor
4. AC Contactor
5. Power Module Assem
bly (refer to Figure 2, p. 11 and
Figure 3, p. 12 for details)
6. Input Filter Capacitor Assembly
7. Input Filter Capacitor Guard Panel
8. Fans, 115 Vac, Inductor (2)
9. Transformer, 3 kVA
10. Fan, 115 Vac, Contactor
11. Resistors, 100k Ohms, 50 W
12. Pre-charge Resistors
13. Relay, Pump, and Control Power Terminals
14. Fuse, Class RK-5, 600 V, 15A (2)
15. Fuse, Class CC, 600 V, 25A (1)
16. Fuse, Class CC, 600 V, 5A (1)
17. Fuse, Class T, 500 V, 150 A (3)
18. Fuse, Class CC, 600 V, 20 A (3)
19. Fuse, Class CC, 600 V, 1 A (3)
20. Ground Lug, 2-600 MCM
21. Nameplate, Power Module
22. Door Inter-lock
23. Line Sync, PCB Assembly
24. Line Sync, PCB Cover
25. Plastic Knob
26. Terminal Block, Fans, 6-Position
27. 1 Microfarad Capacitor (1 μF)
28. Metal Oxide Varistor (m.o.v.)
29. Magnetic Choke
Table 1. Environmental conditions
Condition Specification
Operating Temperature
(inside NEMA 1 enclosure)
0°C to + 55°C (32° to 131°F)
Ambient Temperature
(outside NEMA 1 enclosure)
0°C to + 40°C (32°F to 104°F)
Storage Temperature (Ambient) -40°C to 65°C (40°F to 149°F)
Humidity 5% to 95% (non-condensing)
