UV-PRC001-EN 73
Performance Data
Horizontal Cfg. (D-Coil)
Table P8: HUV; 4-pipe coil with high static motor
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
DA 755 16.9 13.6 3.38 1.3 48.5 2.43 0.5 305
DC 740 19.2 14.7 3.83 1.6 54.4 2.72 0.6 305
DD 740 25.8 17.7 5.16 4.0 47.8 2.39 0.5 305
DE 795 29.3 19.9 5.85 5.0 57.5 2.87 0.7 335
100
DA 1085 27.8 20.8 5.57 3.8 69.0 3.45 1.1 500
DC 1055 30.7 22.3 6.15 4.5 77.4 3.87 1.3 500
DD 1055 38.5 25.9 7.69 9.7 67.7 3.39 1.0 500
DE 1005 39.2 26.1 7.84 10.0 73.3 3.66 1.2 480
125
DA 1220 34.4 25.7 6.88 6.4 80.7 4.03 1.5 470
DC 1350 40.8 29.6 8.16 8.7 99.2 4.96 2.3 525
DD 1350 46.0 32.1 9.21 5.8 86.7 4.34 1.8 525
DE 1295 47.8 32.8 9.57 6.4 96.2 4.81 2.1 525
150
DA 1445 38.1 27.7 7.63 8.7 96.5 4.83 2.3 550
DC 1715 44.7 31.6 8.93 11.6 124.8 6.24 3.8 680
DD 1715 50.9 34.2 10.17 7.8 108.9 5.45 2.9 680
DE 1635 51.8 34.5 10.37 8.3 120.6 6.03 3.5 680
200
DA 1990 48.9 36.9 9.77 13.6 120.6 6.03 3.5 790
DC 1895 53.4 38.6 10.68 15.9 134.1 6.71 4.3 770
DD 1895 60.8 41.8 12.17 10.7 116.7 5.83 3.3 770
DE 1770 63.0 42.5 12.59 11.8 127.7 6.38 3.9 750
