82 UV-PRC001-EN
Performance Data
Steam Coils
Notes:
• Condensate trap for the steam coil option is field installed.
• Static pressure for the K1, K2 options should be modeled after the H1-coil option.
• Steam coils that function at 5 psig or less should not utilize valve control. Valve control may starve the
coil, causing stratification.
Table P17: K1, K2 coils (continued)
Unit Size Coil Type EAT TMBH
5 PSIG
TMBH
10 PSIG
TMBH
15 PSIG
150
K1 -20 166.93 174.89 181.68
K1 0 153.44 161.40 168.19
K1 20 139.94 147.90 154.70
K1 40 126.45 134.41 141.20
K1 60 112.96 120.92 127.71
K1 70 106.21 114.17 120.96
K2 -20 243.70 256.14 263.74
K2 0 224.72 236.38 246.33
K2 20 204.96 216.62 226.57
K2 40 185.20 196.86 206.80
K2 60 165.43 177.09 187.04
K2 70 155.55 167.21 177.16
200
K2 -20 286.51 306.05 317.93
K2 0 266.20 282.43 294.32
K2 20 244.09 258.82 270.71
K2 40 221.28 235.21 274.09
K2 60 197.66 211.59 223.48
K2 70 185.86 199.79 211.67
