84
RTAA-IOM-3
Slide Valve Movement
Movement of the slide valve piston
determines slide valve position which,
in turn, regulates compressor capacity.
Oil flow into and out of the cylinder
governs piston movement, and is
controlled by the normally-closed, load
and unload solenoid valves.
The solenoid valves receive
momentary pulsating “load” and
“Unload” voltage signals from the
UCM based on system cooling
requirements.
To load the compressor,
the UCM opens the load solenoid valve
while keeping the unload solenoid
valve closed. The pressurized oil flow
then enters the cylinder and forces the
slide valve to move over the rotors.
The compressor is unloaded when the
load solenoid valve is kept closed and
the unload solenoid valve is opened.
Oil “trapped” within the cylinder is
drawn out into the lower-pressure
suction area of the compressor. As the
pressurized oil leaves the cylinder, the
slide valve gradually moves away from
the rotors.
When
both solenoid valves are closed,
the present level of compressor loading
is maintained.
Just prior to a normal compressor
shutdown, the unload solenoid valve is
energized and the slide valve moves to
the fully-unloaded position, so the unit
always starts fully unloaded.
Oil Filter
Each refrigerant circuit is equipped with
replaceable-element oil filters. The
filter(s) remove any impurities that
could foul the solenoid valve orifices
and compressor internal oil supply
galleries. This also prevents excessive
wear of compressor rotor and bearing
surfaces. Refer to the maintenance
portion of this manual for
recommended filter element
replacement intervals.
Condenser Fans
The RTAA Series offers either the 15 F
or 0 F ambient fan configuration. On
the 0 F ambient option, the lead fan(s)
on each circuit is a half-airflow (half-
pitch blade) fan(s). Half pitch fans have
a blade pitch of 150 and full pitch fans
have a blade pitch of 27°.
Figures 45 and 46 show the number of
fans installed on each model, the
designation of fan contactors and the
staging of fans as the UCM calls for
more condenser cooling. Fan staging is
a function of the difference between
the saturated condenser refrigerant
temperature and the saturated
evaporator refrigerant temperature,
which in turn is a function of the load
and ambient temperature. Any number
of fans can be operating at a given
time, depending on these variables.
