RTAC-SVX005A-EN
35
Table 6. Evaporator flow and pump performance
Unit Size and
Sequence
(Tons)
Pump
Motor Size
(HP)
Evaporator Pump Pressure
Minimum
Flow (GPM)
Nominal
Flow (GPM)
Maximum
Flow (GPM)
Minimum
Flow (ft)
Nominal
Flow (ft)
Maximum Flow (ft)
155F0 25 193 372 709 129.7 126.7
104.1 @ 709 GPM
155F2-F3 25 193 372 709 143.2 129.4
98.9 @ 606 GPM
170F0 25 202 408 741 129.7 125.5
100.5 @ 741 GPM
170F2 25 202 408 741 143.2 125.8
98.9 @ 606 GPM
200F0 25 217 480 796 129.7 122.2
93.6 @ 796 GPM
200F2-F3 25 217 480 796 143.2 117.0
98.9 @ 606 GPM
250F0 40 217 600 796 117.0 114.2
108.8 @ 796 GPM
250F2-F3 30 217 600 796 123.1 111.5
93.7 @ 796 GPM
300F0 50 309 720 1134 161.0 153.8
123.8 @ 1134 GPM
300F2-F3 50 309 720 1134 142.2 137.3
119 @ 1134 GPM
400F0 50 381 960 1396 161.0 139.3
117 @ 1168 GPM
400F2-F3 50 381 960 1396 141.9 128.8
95.2 @ 1396 GPM
500F0 50 461 1200 1548 143.4 117.2
93 @ 1543 GPM
500F2-F4 50 422 1200 1548 145.9 119.2
86.8 @ 1522 GPM
Note: Table values are recommended maximum and minimum evaporator flow rates or maximum and minimum performance limits of the pump. Always keep the
flow rates within the maximum and minimum flow rates of the above table.
Pre-start Checkout
Unit Location and Mounting
1. Inspect the location for installation and verify service
access clearances.
2. Provide adequate blocking to level trailer.
Inspection
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power can not be
inadvertently energized. Verify that no power is
present with a voltmeter.
1. Inspect all wiring connections. Connections should be
clean and tight.
2. Energize crank case and oil separator heaters 24 hours
prior to start up.
Note: Connecting shore power to the unit without main
power energizes the crankcase and oil separator
heaters. DynaView is powered at the same time.
3. Confirm all service and isolation valves are open.
Electric Wiring
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power can not be
inadvertently energized. Verify that no power is
present with a voltmeter.
• Check for tight connections for the unit power supply
wiring with the circuit breaker to the terminal block.
• Check interlock wiring, chilled water pump control,
chilled water flow interlock and external auto stop
(required). For further details refer to RTAC-SVX01*EN
or unit wiring schematics.
• If remote alarm contacts, limit warning contact,
emergency stop, external chilled water setpoint or
external current limit setpoint are used, refer to RTAC-
SVX01*EN and the unit wiring for further details.
Installation - Electrical
