Trane RTWD User Manual

RLC-SVX14H-GB
10
General data
Table 2 - RTWD High Effi ciency - R134a
RTWD RTWD RTWD RTWD RTWD RTWD RTWD
60 70 80 90 100 110 120
Indicative performances
Cooling Capacity (1) (kW) 235.0 276.0 317.0 365.0 390.0 417.0 452.0
Total Power input in cooling (1) (kW) 48.0 57.0 65.0 74.0 79.0 84.0 91.0
Heating Capacity (2) (kW) 250.3 299.2 340.1 386.8 414.1 443.9 477.4
Total Power input in heating (2) (kW) 57.9 70.1 80.0 90.4 96.1 102.4 109.2
Compressor
Compressor Number per Circuit # 1/1 1/1 1/1 1/1 1/1 1/1 1/1
Type Screw
Model K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1
Evaporator
Quantity # 1111111
Type Flooded shell and tube heat exchanger
Evaporator model E1AM2 E1AM1 E1AMJ E2AM2 E2AM2 E2AM1 E2AMJ
Evaporator Water Content volume (l) 37.0 40.2 45.2 57.9 57.9 62.3 65.4
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 4.5 5.0 5.7 7.0 7.0 7.7 8.2
Evap. Water Flow rate - Maximum
(3)
(l/s) 16.6 18.4 21.1 25.7 25.7 28.2 30.0
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
411
(114.3 mm)
411
(114.3 mm)
411
(114.3 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s) 3.0 3.3 3.8 4.7 4.7 5.1 5.4
Evap. Water Flow rate - Maximum
(3)
(l/s) 11 12.2 14.1 17.2 17.2 18.8 20
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
3"
(88.9 mm)
3"
(88.9 mm)
3"
(88.9 mm)
4"
(114.3 mm)
4"
(114.3 mm)
4"
(114.3 mm)
4"
(114.3 mm)
Condenser
Quantity # 1111111
Type Shell and Tube Heat Exchanger
Condenser model C1AM2 C1AM2 C1AMJ C2AM3 C2AM2 C2AM2 C2AMJ
Condenser Water Content volume (l) 45.1 45.1 52.2 58.1 62.7 62.7 68.3
Two pass condenser
Cond. Water Flow rate - Minimum (l/s) 5.4 5.4 6.6 7.3 8.1 8.1 9.1
Cond. Water Flow rate - Maximum (l/s) 19.9 19.9 24.4 26.9 29.8 29.8 33.2
Nominal water connection size
(Grooved coupling)
(in) -
(mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
5 1”
(139.7 mm)
Dimensions (4)
Unit Length (mm) 3320 3320 3320 3320 3320 3320 3320
Unit Width (mm) 1070 1070 1070 1060 1060 1060 1060
Unit Height (mm) 1940 1940 1940 1960 1960 1960 1960
Weights (5)
Shipping Weight (kg) 2568 2573 2637 2812 2849 2883 3065
Operating Weight (kg) 2650 2658 2673 2928 2970 3008 3198
System data (6)
Nb of refrigerant circuit # 2222222
Minimum cooling load % % 30 30 30 30 30 30 30
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
(kg) 45/45 45/45 44/44 55/55 55/56 55/55 54/54
Oil charge Circuit1 / Circuit 2 (l) 6.8/6.8 6.8/6.8 6.8/6.8 6.8/6.8 6.8/9.9 9.9/9.9 9.9/9.9
POE Oil type OIL048E or OIL023E
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
