Page #33 background imageLoading...
Page #33 background image
BAS-SVX48H-EN
33
Power Supply
Read the following Warnings, Cautions, and Notices before proceeding.
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr bbeeffoorree sseerrvviicciinngg ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg.. FFoollllooww
pprrooppeerr lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr ccaann nnoott bbee iinnaaddvveerrtteennttllyy
eenneerrggiizzeedd.. VVeerriiffyy tthhaatt nnoo ppoowweerr iiss pprreesseenntt wwiitthh aa vvoollttmmeetteerr..
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
SShhaarriinngg 2244 VVaacc ppoowweerr bbeettwweeeenn ccoonnttrroolllleerrss ccoouulldd rreessuulltt iinn eeqquuiippmmeenntt ddaammaaggee..
IImmppoorrttaanntt:: After installation, ensure that the 24 Vac transformer is grounded through the
controller. Measure the voltage between chassis ground and any ground terminal on
the UC400 Controller. Expected measurement :Vac £4.0 V
A separate transformer is recommended for each UC400 Controller. The line input to the
transformer must be equipped with a circuit breaker sized to handle the maximum transformer
line current. If a single transformer is shared by multiple UC400 Controllers:
The transformer must have sufficient capacity.
Polarity must be maintained for every controller powered by the transformer.
IImmppoorrttaanntt:: If the polarity is inadvertently reversed between two controllers powered by the
same transformer, a difference of 24 Vac occurs between the grounds of each
controller, which can result in:
Partial or full loss of communication on the entire BACnet MS/TP link.
Improper function of the UC400 Controller outputs.
Damage to the transformer or a blown transformer fuse.
Transformer Recommendations
A 24 Vac power supply must be used for proper operation of the binary inputs, which requires 24
Vac detection. In addition, the spare 24 Vac outputs can be used to power relays and TRIACS:
AC transformer requirements:
NNoottee:: The transformer must be sized to provide adequate power to the controller (12 VA) and
outputs (maximum 12 VA per binary output).
UL listed, Class 2 power transformer.
24 Vac ±15%, device max load 24 VA.
CE-compliant installations: The transformer must be CE marked and SELV compliant per IEC
standards.
Wiring Requirements
Install the power supply circuit in accordance with the following guidelines to ensure proper
operation of the UC400 Controller:
A dedicated power circuit disconnect switch must be near the controller, easily accessible by
the operator, and marked as the disconnecting device for the controller.
18 AWG (0.823 mm
2
) copper wire is recommended for the circuit between the transformer
and the controller.
WWiirriinngg IInnssttaallllaattiioonn
