Trane WC*150B***G Series User Manual

WC-IOM-7 • Packaged Heat Pump 53
Troubleshooting
Te s t 3
System Mode and Fan Selection
The combined resistance of the Mode selection switch and the Fan selection
switch can be measured between terminals 2 and 4 on the Zone Sensor. The
possible switch combinations are listed on the following page with their
corresponding resistance values.
Te s t 4
LED Indicator Test, (SYS ON, HEAT, COOL & SERVICE)
Method 1
Testing the LED using a meter with diode test function. Test both forward and
reverse bias. Forward bias should measure a voltage drop of 1.5 to 2.5 volts,
depending on your meter. Reverse bias will show an Over Load, or open circuit
indication if LED is functional.
Method 2
Testing the LED with an analog Ohmmeter. Connect Ohmmeter across LED in one
direction, then reverse the leads for the opposite direction. The LED should have
at least 100 times more resistance in reverse direction, as compared with the
forward direction. If high resistance in both directions, LED is open. If low in both
directions, LED is shorted.
Method 3
To test LED’s with ZSM connected to unit, test voltages at LED terminals on ZSM.
A measurement of 32 VDC, across an unlit LED, means the LED has failed.
Note: Measurements should be made from LED common (ZSM terminal 6 to
respective LED terminal). Refer to the Zone Sensor Module (ZSM) Terminal
Identification table at the beginning of this section.
Programmable & Digital Zone Sensor Test
Testing serial communication voltage
1. Verify 24 VAC is present between terminals J6-14 & J6-11.
2. Disconnect wires from J6-11 and J6-12. Measure the voltage between J6-11
and J6-12, should be about 32 VDC.
3. Reconnect wires to terminals J6-11 and J6-12. Measure voltage again
between J6-11 and J6-12, voltage should flash high and low every 0.5
seconds. The voltage on the low end will measure about 19 VDC, while the
voltage on the high end will measure from approximately 24 to 38 VDC.
