Trane Wired Temperature Sensors User Manual

BAS-SVX10C-EN 37
Wiring Diagrams
RT1 thermistor,
10 k at 25°CΩ
1
2
4
Calibration
Pot 1 (see )Note 1
R7, 3.92 kΩ
Note 1:
Pot 1 and
Pot 2 are
factory
calibrated.
Field
adjustment
voids
warranty.
3
5
R6, 8.45 kΩ
Auto
On
R8, 3.92 kΩ
Heat Setpoint
Pot 3,
1 kΩ
Calibration Pot 2 (see )Note 1
R1, 4.87 kΩ
R2, 2.32 kΩ
R3, 7.68 kΩ
R4, 19.6 kΩ
Heat
Auto
Off
Cool
CR2
Green
CR4
Green
CR3
Green
CR1
Red
6
7
9
8
10
LED Service
LED Heat
LED Common
LED Sys_On
LED Cool
R5, 34.8 kΩ
EM Heat
R9, zero Ω
Signal common
Cool setpoint (CSP)
Heat
Setpoint (HSP)
Zone
temperature
TB1
Mode
(Sys/Fan switch)
System
SW1
Fan
SW2
Cool setpoint
Pot 4,
1 kΩ
Dwg source: X39641094-01
RT1 thermistor,
10 k at 25°CW
Temperature
setpoint
Pot 5,
1 kW
1
2
4
Calibration
Pot 1 (see )Note 1
Note 1:
Pot 1 is
factory
calibrated.
Field
adjustment
voids
warranty.
3
R6, 8.45 kW
Auto
On
R1, 4.87 kW
R2, 2.32 kW
R3, 19.6 kW
Heat
Off
Cool
Fan
SW2
R4, 34.8 kW
EM Heat
CR3
Green
6
7
LED Heat
LED Common
TB2
R9, zero W
Signal common
Cool setpoint (CSP)
Zone
temperature
TB1
Mode
(Sys/Fan switch)
System
SW1
Dwg Source: X39641099-01
X1379084701
X1379085201
Temperature sensors with fan and
system control
