47
Pub. No. 22-5128-02
69-1216
Clearing Schedule Period
Suppose you want to skip a schedule period or periods for a particular day because you don’t need them. For
example, if Saturday is a day you normally stay at home from school or work, you can clear the Leave and
Return periods for this day and keep the Wake and Sleep periods. You can always reprogram the periods later.
NOTE: The clear feature applies to 7-Day and 24-Hour Operation. The thermostat must be in the program
mode to use the clear feature. Go to step 2 if the thermostat is already in the program mode (Set
Program displays in upper left corner).
1. Press Leave, Return or Sleep to
enter program mode.
Leave Return Sleep
M17066
Heat
Auto
Fan
Leave
AM
Mon
Set Program
Setting
By pressing Leave, Return, or Sleep, you enter the program mode.
Example display shows 8:00 AM on Monday in the Leave period, with Heat set for 62°
To Next Page
