Triumph DAYTONA 650 User Manual

!!
!
General Information
Page 22
TEC0010
1
1. Key Number Tag
IGNITION KEY
In addition to operating the steering
lock/ignition switch, the ignition key is
required to operate the seat lock and fuel
tank cap.
When the motorcycle is delivered from the
factory, two keys are supplied together with
a small tag bearing the key number. Make
a note of the key number and store the spare
key andkey number tag in a safe place away
from the motorcycle.
Your authorised Triumph dealer can supply
a replacement key cut from details of the key
number or can cut a new key using the
original as a master.
CAUTION: Do not store the
spare key with the motorcycle
as this will reduce all aspects of
security.
TEC0011
1
4
3
2
5
1. Ignition Switch/Steering Lock
2. LOCK position
3. OFF position
4. ON position
5. P (Park) position
IGNITION SWITCH/STEERING LOCK
This is a four position, key operated switch.
The key can be removed from the switch
only when it is in the OFF, LOCK or P
(PARK) position.
TO LOCK: T urn the key to the ‘OFF’
position, push and fully release the key, then
rotate it to the ‘LOCK’ position.
‘PARKING’: Turn the key from the ‘LOCK’
position to the ‘P’ position. The steering
remains locked.
NOTE:
S Do not leave the steering lock in
the ‘P’ position for long periods as
this will cause the battery to
discharge.

Triumph DAYTONA 650 Specifications

General

Displacement	646 cc
Transmission	6-speed
Rear Brakes	Single 220mm disc, single-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, DOHC, inline 4-cylinder
Max Torque	68 Nm @ 11, 000 rpm
Frame	Aluminum
Rear Suspension	Monoshock with adjustable preload
Front Brakes	Twin 308mm floating discs, 4-piston calipers
Seat Height	825 mm
Dry Weight	165 kg
Ignition	Digital
Final Drive	Chain
Length	2, 060 mm
Wheelbase	1395 mm
Fuel Capacity	17.5 liters (4.6 US gal)
