FIRMER 3 4 4 4 4 N/A
RIDER AND
PASSENGER
3 4 4 4 4 N/A
* Number of adjuster clicks out from the fully screwed in position.
+ Number of visible graduation lines.
NOTE:
This chart is only a guide. Setting requirements may vary for rider weight and personal
preferences. See the following pages for details of how to adjust your suspension.
Adjuster Location
Front
The spring pre--load and rebound damping
adjusters are located at the top of each fork.
The compression damping adjusters are
located at the bottom of each fork.
Rear
The compression damping adjuster is
located on the damping fluid reservoir.
The rebound damping adjuster is located at
the base of the suspension unit on the left
hand side of the motorcycle.
The spring pre-load adjuster cannot be reset
with the suspension unit in the frame.
Please refer to your authorised Triumph
dealer for adjustment of this item.
WARNING: Owners should
not attempt to adjust the rear
suspension spring pre-load setting.
Only an authorised Triumph dealer
has the necessary tools, equipment
and specialist knowledge to make
adjustments to the rear suspension
pre-loa d settings. In addition, due to
the forces of the rear spring under
compression, specialist safety
equipment is also needed if the
adjustment is to be made without risk
of injury.
Making adjustments without this
specialist knowledge, or without
access to the necessary specialist
tools and safety equipment could
cause personal injury and a
dangerous riding condition leading to
loss of motorcycle control and an
accident.
