STEP 16: Figure 4 Page 18
For Floor Plate Style Lift, mount the floor plate as Figure 4.
STEP 17:
Install the swing arms on the carriages using the included 1 1/2” diameter pins. Check to
make sure the rack on the lock should fully engage with the gear on the arm.
STEP 18:
Adjust the carriage cables tension: adjust each cable to approximately 1/2” side-to side play.
Check the latch releases to insure the carriage is still sitting on the appropriate latch.
STEP 19:
Remove the vent plug from the power unit and fill the reservoir. Use a Ten Weight (SAE-10)
non-foaming, non-detergent hydraulic fluid. The unit holds approximately twelve quarts.
STEP 20:
Make the Electrical hookup to the 220V Single Phase Power Unit. It is recommended that a
220 Volt, 20amp twist lock plug be installed in the power line just ahead of the power unit‘s
size wire for a 20amp circuit.
Warning-the wiring must comply with local code. Have a certified electrician make the
electrical hook-up to the power unit. Protect each circuit with time delay fuse or circuit
breaker 208V-230V single Phrase 60Hz 30amp. Motor cannot run on 50Hz without a
physical change to motor.
ATTENTION: IF 380V POWER UNIT APPLIES, PLEASE ADJUST AND USE RELATIVE
TWIST LOCK AND TIME DELAY FUSE OR CIRCUIT BREAKER ACCORDINGLY!
STEP 21:
Do not place any vehicle on the lift at this time. Cycle the lift up and down several times to
insure latches click together and all air is removed from the system. To lower the lift, both
latch releases must be manually released. Latches will automatically reset once the lift
ascends approximately 17” from base. If latches click out of sync, tighten the cable on the
one that clicks first.
RAISE THE LIFT
Press button on power unit. The latch mechanism will ‘trip over’ when the lift raises and
drops into each latch stop. But, to lock the lift you must press the Lower level to relieve the
hydraulic pressure and let the latch set tight in a lock position.
Always lock the lift before going under the vehicle. Never allow anyone to go under the lift
when raising or lowering. Read the safety procedures in the manual.
Note: It is normal for an empty lift to lower slowly-it may be necessary to add weight.
