DEFINITION
This lift is a 9000 lb. capacity, 2-Post Lift with a latch system. The
safety latch is in contact with the latch rack as the lift ascends and
drops into place. The safety latch engages in rack at 3” increments
beginning about 16”from the ground. The latch must be manually
disengaged for the lift to descend. The latch is released by raising the
latch up off the latch rack and pulling the release cable. Once the raise
button is pressed, the latch will automatically re-engage after
approximately 3” of travel. Heavy bearings and heavy-duty leaf chains
are used throughout the lift. The work is done with the heavy-duty
chain connected to a 2 1/2” cylinder, driven by a hydraulic pump
capable of providing 3,000psi.
Please read the Safety Procedures and Operation Instructions in this
manual before operating and installing the lift. Proper installation is
very important. To minimize the chance of making an error in
installation, please read this manual through carefully before
beginning installation. Check with building owner and/or an engineer
when applicable. The lift should be located on a relatively level floor 4”
thick and 3,000psi concrete sufficiently cured.
This is a vehicle lift installation/operation manual and no attempt is
made or implied herein to instruct the user in lifting methods particular
to an individual application. Rather, the contents of this manual are
intended as a basis for operation and maintenance of the unit as it
stands alone or as it is intended and anticipated to be used in
conjunction with other equipment.
Proper application of the equipment described herein is limited to the
parameters detailed in the specifications and the uses set forth in the
descriptive passages.
