Trojan FOCUS 360 User Manual

10133-24
10. PARTS LIST
NO. PART DESCRIPTION QTY
1 Main Base 1
2 Rear Base 1
3 VerticalPost 1
4 Guide Rod 2
5 Top Beam 1
6 ButteryExtension 1
7 LeftButteryArm 1
8 RightButteryArm 1
9 Seat Cushion Support 1
10 Seat Support Post 1
11 LegExtension 1
12 Arm Curl Frame 1
13 Bench Press Arm 1
14 Handle Tube 2
15 Left Adjustable Plate 1
16 Right Adjustable Plate 1
17 Left Press Arm 1
18 Right Press Arm 1
19 Connect Piece 3
20 Foam Rod (Short) 1
21 Foam Rod (Long) 1
22 Lat Bar 1
23 Curl Bar 1
24 SinglePulleyBracket 2
25 IntersectPulleyBracket 1
26 DoublePulleyBracket 1
27 Arm Curl Cushion 1
28 Seat Cushion 1
29 BackrestCushion 1
30 Weight Selection Rod 1
31 Top Plate 1
32 Weight Plate 9
33 Weight Base Plate 1
34 Weight Selection Pin 1
35 Handle Foam 4
36 50x50mmSquareEndCap 2
37 50mm Square End Plug 10
38 50x45mmSquareBushing 3
39 1” Round End Plug 10
40 Square Rubber Bumper 3
41 Bumper Cap 2
42 5/8” Plastic Dome Cap 4
43 1/2” Plastic Dome Cap 2
44 Foam Roll 4
45 Round Bumper 2
46 Foam Handle (Short) 2
NO. PART DESCRIPTION QTY
47 Pop Pin 2
48 Pt-1Pop Pin 3
49 Hook 6
50 Pulley 15
51 Big Pulley 1
52 Chain (Short) 2
53 Chain (Long) 1
54 Pivot Shaft 1
55 45mm Square End Plug 4
56 Foam Handle (Long) 2
57 Pin 1
58 Taper End Plug 1
59 Upper Cable 1
60 Lower Cable 1
61 ButteryCable 1
62 3/8”x1”HexBolt 10
63 3/8”x1-3/8”HexBolt 2
64 3/8”x2”HexBolt 9
65 3/8”x2-5/8”HexBolt 6
66 3/8”x2-7/8”HexBolt 6
67 3/8”x3”HexBolt 2
68 3/8”x3-3/8”HexBolt 1
69 1/2”x3-3/8”HexBolt 1
70 M10x25mmScrew 3
71 M8x16mmHexBolt 6
72 M8x63mmHexBolt 2
73 3/8”Locknut 26
74 1/2”Locknut 1
75 5/8”Locknut 4
76 M8 Washer 12
77 3/8” Washer 62
78 1/2” Washer 2
79 Washer(T3.0xØ13xØ32) 1
80 5/8” Washer 4
81 Washer(T3.0xØ46xØ26) 1
82 Washer(Ø36xØ11xT3.0) 2
83 3/4” Oil Bushing 10
84 CopperBushing(Ø44xØ39.4xØ19.1x12) 4
85 CopperBushing(Ø50xØ44xØ12.8x12) 2
86 Plastic Bushing 1
87 Bushing 8
88 CopperBushing(Ø44xØ39.4xØ25.2x12) 4
89 3/8” Plastic Dome Cap 2
90 M8x60mmHexBolt 2
91 M8Locknut 2
