TSC DA310 Series User Manual

- 4 -
DA220/320 Series
Product option feature for DA220/320 series
User
option
Dealer
option
Factory
option
Peel-off module
○
Guillotine cutter (full cut or partial cut)
○
Main board for USB & IE ports only
○
Real time clock
○
Internal 802.11 a/b/g/n wireless module
○
Internal Bluetooth 4.0 module
○
1.5” adapter for i.5” paper core
○
KP-200 Plus keyboard display unit (option with RS-232)
○
KU-007 Plus programmable smart keyboard (option with
RS-232)
○
External Bluetooth connectivity (option with RS-232)
○
External roll mount, media OD. 214 mm (8.4”) with 76.2
mm (3”) core
○
1.3 General Specifications
General Specifications
Physical
dimensions
172 mm (W) x 165 mm (H) x 195 mm (D)
Mechanism
Plastic with double-walled clamshell design
Weight
1.5 kg
Power
External universal switching power supply
Input: AC 100-240V, 50-60Hz
Output: DC 24V, 2.5A, 60W
Environmental
condition
Operation: 5 ~ 40˚C, 25~85% non-condensing
Note : Peeler mode : 40˚C/ 45%
Storage: -40 ~ 60 ˚C, 10~90% non-condensing
Environmental
concern
Comply with RoHS, WEEE
1.4 Print Specifications
Print Specifications
203 dpi models
300 dpi models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 11.8 dots)
Max. print speed
(inches per second)
152.4 mm (6”)
102 mm (4”)
2,3 ips for peeler mode
Max. print width
108 mm (4.25”)
105.7 mm (4.16”)
