TSC DA310 Series User Manual

- 25 -
4.3 Printer Initialization
Printer initialization is used to clear DRAM and restore printer settings to defaults.
Printer initialization is activated by the following procedures.
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3. Release the button when LED turns green after 5 amber blinks. (Any green will do during the 5 blinks).
 The LED color will be changed as following:
Amber  red (5 blinks)  amber (5 blinks)  green (5 blinks)  green/amber (5 blinks)  red/amber
(5 blinks)  solid green
Printer configuration will be restored to defaults as below after initialization.
Parameter
Default setting
Speed
127 mm/sec (5 ips) (203DPI)
76.2 mm/sec (3 ips) (300 DPI)
Density
8
Media Width
4” (101.5 mm)
Media Height
4” (101.5 mm)
Sensor Type
Gap sensor
Print Direction
0
Reference Point
0,0 (upper left corner)
Gap Offset
0
Post-Print Action
Tear mode
Serial Port Settings
9600 bps, none parity, 8 data bits, 1 stop bit
Code Page
850
Country Code
001
Clear Flash Memory
No
Note:
When printer initialization has done, please calibrate the gap or black mark sensor before printing.
