TSC TTP-345 Service Manual

14
1.3. Supply Specification
1.3.1. Paper
Item
Specification
Type
Label (Continuous , Die-cut , Fan-fold).
Wound Type
Outside wound.
Width
20~112mm (0.78" ~ 4.4")
Length
( for peel and cutter )
10mm ~ 1000mm (0.4” ~ 39”).
25.4mm ~ 1000mm (1” ~ 39”).
Thickness
0.06mm ~ 0.19mm.
Roll Diameter
5”.
Roll Core Diameter
25.4mm ~ 76.2mm (1” ~ 3”).
Gap Height
2mm min.
Black Mark Height
2mm min.
Black Mark Width
8mm min.
1.3.2. Ribbon
Item
Specification
Type
Wax, Wax / Resin, Resin.
Core Diameter
1".
Width
Max 110mm.
Capacity
300m with 1" core.
Wound Type
Outside wound.
Ribbon End
Clear or silver end tape.
