3.8. Replacing Black Mark Sensor Assembly
1. Please refer to 3.1 for disassembling the lower cover and lower inner cover.
2. Disconnect all hardness.
3. Upside down the lower inner cover. Remove 4 screws and remove the plastic
laminate.
4. Remove 1 screw from the black mark sensor.
5. Upside down the lower inner cover.
6. Replace the black mark sensor assembly.
7. Reassemble parts in reverse procedures.
