41
7. LED and Button Operation
7.1 LED
LED Color Description
Green/ Solid
This illuminates that the power is on and the device is
ready to use.
Green/ Flash This illuminates that the system is downloading data
from PC to memory and the printer is paused.
Amber
This illuminates that the system is clearing data from
printer.
Red / Solid This illuminates printer head open, cutter error.
Red / Flash This illuminates a printing error, such as head open,
paper empty, paper jam, ribbon empty, or memory error
etc.
7.2 Button Operation
Feed
z Press the button when the LED is green.
It feeds the label to the beginning of the next label.
Pause
z Press the feed button during printing
The printing job is suspended.
Ribbon Sensor and
Gap/Black Mark
Sensor Calibration
1. Turn off the power switch.
2. Hold on the button then turn on the power switch.
3 Release the button when LED becomes red and blinking.
(Any red will do during the 5 blinks).
It will calibrate the ribbon sensor and gap/black mark
sensor sensitivity.
The LED color will be changed as following order：
Amber Æ red (5 blinks) Æ amber (5 blinks) Æ green
(5 blinks) Æ green/amber (5 blinks) Æ red/amber (5
blinks) Æ solid green
Note:
Please select gap or black mark sensor by GAP or BLINE
command prior to calibrate the sensor.
For more information about GAP and BLINE command,
please refer to TSPL2 programming manual.
