Standard Doors
7U-Line Service
General Information
Door Alignment and Adjustment
Align and adjust the door if it is not level, or is not sealing properly. If
the door is not sealed the unit may not cool properly, or excessive
frost may form in the interior.
NOTICE
Properly aligned, the door’s gasket should be firmly in
contact with the cabinet all the way around the door (no
gaps). Carefully examine the door’s gasket to assure that it is
firmly in contact with the cabinet. Also make sure the door
gasket is not pinched on the hinge side of the door.
To align and adjust the door.
1. Loosen (do not remove) top and bottom hinge screws.
2. Align door squarely with cabinet.
3. Make sure gasket is firmly in contact with cabinet all the way
around the door (no gaps).
4. Tighten bottom hinge screws.
5. Tighten top hinge screws.
Door Reversability
(Does not apply to ADA or lock units)
Location of the unit may make it desirable to mount the door on the
o
pposite side of the cabinet.
Models with black and white doors are field-reversible.
Stainless steel models with glass doors without locks are 
field-reversible. See the table at the front of this book for a summary
of units that are reversible.
Stainless steel models without glass doors must be ordered right- or
le
ft-hand hinged.
Reversing the Door
(Does not apply to ADA or lock units)
The hinge hardware will be removed and reinstalled on the opposite
s
ide of the cabinet.
The hinge plate is flipped over when it is reinstalled on the opposite
s
ide of the cabinet.
Plastic
Plug Hole
Plastic
Plug Hole
Right Side
Door Swing
Left Side
Door Swing
Remove grille.
Remove the grille, see MAINTENANCE section of this guide.
Remove top hinge, and door.
1. Hold door to keep it from falling.
2. Remove top hinge from cabinet by removing three or four screws,
depending on model.
3. Remove door by tilting forward and lifting door off bottom hinge.
4. Remove three or four plastic screw plugs from hinge holes on the
o
pposite side. Reinstall into holes where the hinge was removed.
Ensure not to scratch cabinet.
Remove bottom hinge.
1. Remove bottom hinge from cabinet. Some models will have a
guss
et with two screws. Other models will have a plate with
three screws.
2. Remove corresponding screws on opposite side of cabinet. On
some models there may be a nut behind one or both screws on
either side.
