UBio-X Pro Lite User Guide
73
UNIONCOMMUNITY Co., Ltd.
Addr : 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu,
Seoul, Korea (zip code : 05836)
Tel : +82-2-6488-3000, Fax : +82-2-6488-3099
E-Mail :sales@unioncomm.co.kr; http://www.unioncomm.co.kr
- Picture: The image log data is saved in the folder ‘UbioXpro / Terminal ID (8digit) /
log / pictures’ on the SD Card as jpg file.
- Export all: It can export all things User Data, Event Log, System Option, Picture to the
SD Card.
▶Import
It copies the data from the SD Card to the terminal.
- User Data: It copies the user DB from the SD Card to the folder ‘unisuser’ in the terminal.
- System Option: The option setting value of the terminal is copied to the folder ‘UbioXpro
/ config’ in the terminal.
After importing the data, the UBio-X Pro terminal should be rebooted to apply new data
& options.
▶Others
- Theme: The voice file in the ‘UbioXpro /audio’ folder in the SDcard is copied to the terminal.
If you want to replace the authorization success (user_ok.mp3) and the authorization
fail (user_fail.mp3) message with the user voice, set the name of the user voice file as
(user_ok.mp3), (user_fail.mp3) respectively which the user voice will play.
And also the checkbox “User Voice” on [3.7.1. Sound] should be checked.
- F/W upgrade: It upgrades the firmware by the SD Card.
(The firmware should be in the ‘UbioXpro’ folder on the SD Card.)
If you want to finish working and move to the upper menu, click the [OK] or [Back]
button.
3.11. User’s file download
If necessary, the user can change the background screen or voice message with this
function. It can be fulfilled by copy with SD Card or downloading the user file from the
UNIS server program.
3.11.1. How to change voice sound
If you select the ‘Download customized file’ in the UNIS program, the following window
appears.
If you select ‘Sound file in success (.wav)’ as the file type and click ‘Send’ button after
To Next Page
