Wall-Mount Installation of a Cradle
Before mounting the cradle onto the wall, read the instruction made below.
Mounting Kit (Optional article
4070-900011G
)
If you want to mount the MS840 cradle onto the wall, an iron plate, two screws, and
two plastic conical anchors are required.
Iron Plate 2 Screws 2 Plastic Conical Anchors
Before mounting the cradle onto the wall, prepare a screwdriver and read the
step-by-step instructions made below.
Follow the steps below to mount the cradle onto the wall.
Step 1: Loose and remove 2 screws from the stand of cradle by using a screwdriver.
Then, remove the stand from the cradle.
Step 2: Move the stand of cradle to the lower portion of the cradle from the upper
portion adjacent to the antenna. Then, secure the stand to the cradle with 2
screws by using the screwdriver.
9
