Maintenance
5-4 OPERATION GUIDE
Cleaning the Charger and the Registration Roller
1
Slide the charger cleaner knob backwards
and forwards 2 to 3 times, then return it to
the CLEANER HOME POSITION.
If the charger cleaner is not properly
restored a black band will appear on copies.
2
Use the cleaning cloth supplied to clean
paper dust and dirt accumulated on the
metal registration roller (A) inside the
machine.
Do not touch the black transfer roller (B).
3
After cleaning, align the pins (C) on both
sides of the process unit with the guides
inside the machine, and carefully slide the
process unit into the machine until in stops.
4
Close the front cover.
5
Close the top cover.
6
When the toner container is replaced, reset the toner gauge. For details, refer to the
Advanced Operation Guide.
(A)
(B)
(C)
(C)
