2LV/2L1/2L2/2MS/2MT
2-4-3
(3) Firmware environment commands
The printer maintains a number of printing parameters in its memory. These parameters may be changed per-
manently with the FRPO (Firmware RePrOgram) commands.
This section provides information on how to use the FRPO command and its parameters using examples.
Using FRPO commands for reprogramming the firmware
The current settings of the FRPO parameters are listed as the optional values on the service status page.
Note: Before changing any FRPO parameters, print out a service status page, so you will know the parameter
values before the changes are made. To return FRPO parameters to their factory default values, send the
FRPO INIT (FRPO-INITialize) command.(!R! FRPO INIT; EXIT;)
The FRPO command is sent to the printer in the following sequence:
!R! FRPO parameter, value; EXIT;
Example: Changing emulation mode to PC-PR201/65A
!R! FRPO P1, 11; EXIT;
FRPO parameters
Item FRPO Setting values
Factory
setting
Top margin A1 Integer value in inches 0
A2 Fraction value in 1/100 inches 0
Left margin A3 Integer value in inches 0
A4 Fraction value in 1/100 inches 0
Page length A5 Integer value in inches 13
A6 Fraction value in 1/100 inches 61
Page width A7 Integer value in inches 13
A8 Fraction value in 1/100 inches 61
Default pattern resolution B8 0: 300 dpi
1: 600 dpi
0
Copy count
C0 Number of copies to print:1-999 1
Page orientation C1 0: Portrait
1: Landscape
0
Default font No. C2
C3
C5
Middle two digits of power-up font
Last two digits of power-up font
First two digits of power-up font
0
0
0
PCL font switch C8 0:HP compatibility mode (Characters higher
than 127 are not printed.)
32:Conventional mode (Characters higher than
127 are printed. Supported symbol sets: ISO-
60 Norway [00D], ISO-15 Italian [00I], ISO-11
Sweden [00S], ISO-6 ASCII [00U], ISO-4 U.K.
[01E], ISO-69 France [01F], ISO-21 Germany
[01G], ISO-17 Spain [02S], Symbol [19M)
0
